•Made from a single-material polypropylene using a biaxial stretching process.

•Printability: Stable surface tension. Compatible with Flexo, Gravure, Offset, Screen, and UV printing. Supports premium hot foil stamping to deliver a sophisticated, high-end aesthetic.

•Functionality: Inherent anti-static properties and excellent resistance to oils and grease，abrasion resistance.

•Visual effects: clear and vivid surface textures; embossing processes create various patterns on the surface, enhancing packaging aesthetics and premium feel.

Keyful CPP-DP uses single-material PP to create diamond effect CPP film. Its clear and striking diamond-shaped three-dimensional texture significantly enhances the premium feel and recognizability of packaging. With stable surface tension, it is compatible with various printing methods and supports hot stamping and hot foiling, creating superior light and shadow layering. It also features anti-static, oil and stain resistance, and abrasion resistance.

We focus on the research & development, production, manufacturing, and supply of various flexible, environmentally friendly, and biodegradable packaging films, covering BOPP, BOPET, BOPA, PE, and recyclable single-material films, and are committed to meeting the diverse packaging solution needs of the market.

Keyful CPP-DP CPP Diamond Pattern Film is made from a single PP material, biaxially stretched to form a film with a distinct diamond texture and three-dimensional embossed appearance. It features stable surface tension, ensuring smooth compatibility with Flexo, Gravure, Offset, Screen, and UV printing, guaranteeing superior ink distribution and pattern layering. It also supports premium hot foil stamping, enhancing the high-end light and shadow effects of the Diamond pattern lamination film.

Functionally, it possesses inherent antistatic properties and offers good resistance to oils and grease, as well as everyday wear and tear, making it suitable for mass production and complex processes. As a Geometric diamond CPP film, it has a delicate feel and a strong visual identity, ideal for custom packaging that requires a “diamond-like” texture.

Applications

  • Paper-Plastic Lamination Industry: Lamination for luxury gift boxes, folding cartons, shopping bags, books, and various product packaging.
  • Label Industry: Printable labels, compatible with various adhesives, with customizable adhesion.
  • Flexible packaging industry: surface printing material for multi-pouch packaging.

Technical Properties (Typical Values)

Property Unit Result Test method
Thickness microns 80±2 DIN 53 370
Tensile strength MD/TD MN/m² 10 ASTM D 882
10
Elongation at break MD/TD % 420 ASTM D 882
380
Heat shrinkage MD/TD % 0.9 ASTM D1204 100°C / 10 min
0.5
Surface Wetting Tension
Laminated Side		 dyne/cm >32 GB/T 14216
Surface Wetting Tension
Non-Laminated Side		 dyne/cm >32 GB/T 14216
Optical: Gloss Haze (wide angle) GU 2~3 ASTM D2457 60°C

All properties are tested under standard laboratory conditions: 23±2ºC; 50±5% RH, unless otherwise stated. Where relevant, tests are based on international testing standards. Metallising is conducted by a sub-contractor. MD – Machine Direction TD – Transverse Direction.

    Name*

    Email*

    Phone

    Country

    Company Name

    Subject

    Message*

    * Required

    The texture comes from a combination of structure and embossing processes, offering strong batch applicability and facilitating a consistent appearance for packaging within the same series.

    Maintaining stable surface wetting tension, it can be used for Flexo, Gravure, Offset, Screen, and UV printing, reducing on-press fluctuations and the risk of pattern blurring.

    Supports premium hot foil stamping; hot stamping on the diamond embossed texture usually presents a more pronounced layering effect and metallic light and shadow.

    It possesses natural antistatic properties and good resistance to oils/grease, along with a degree of abrasion resistance, improving stability during transportation and lamination.

    Suitable for surface lamination/composite decoration of luxury gift boxes, folding cartons, shopping bags, books, etc., enhancing the finished product’s texture.

    It can be matched with various adhesive systems and supports customized bonding solutions; it is recommended to conduct small-scale tests under the target adhesive and peel requirements for confirmation.

    It can be used as a surface printing material; the diamond texture enhances visual recognition and tactile differentiation.

    Supports B2B customization services; the specific thickness, texture intensity, and printing/hot stamping process matching need to be evaluated based on project requirements.
